  • Pre-Order Now For End Of November 2022 Delivery
Regular price$999.99
/

We are currently accepting Pre-Orders for a the first batch of Wuxn WXR 3d Printers. The first batch of WXR printers will ship by the End of November 2022.

Limited Quantity Available Pre-Order Today!

The Wuxn WXR Ecosystem is our third generation of highly powered professional desktop 3D printers made in the USA. Rapidly manufacture quality prototypes & products in-house by utilizing the Wuxn WXR, Wuxn Classic Filament, & WuxnSlicer in conjunction.

Wuxn WXR Main Features:

  • Fully Assembled Ready To Run Out Of The Box
  • Wuxn Wizards
  • Gantry Alignment
  • Mesh Bed Leveling
  • Profile Linear Guide Rails
  • Removable Print Surfaces
  • Filament Sensor
  • Automatic Filament Loading
  • Automatic Memory Card Detection
  • Quality built in the USA
  • Full Color Touch Screen
  • Wuxn Classic Filament
  • WuxnSlicer



Wuxn WXR Specifications:

Mechanical

Frame

Engineering Grade Aluminum & Steel w/ Viscoelastic Damping

Dimensions: [440x535x480]mm/[17x21x19]in

Print

Volume

Cartesian Rectilinear Coordinates

Dimensions: [250x210x250]mm/[10x8x10]in

Hotend

All-Metal Slice Engineering CopperHead w/ Bimetallic Heatbreak

Maximum Temperature: 295C/563F

Extruder

Wuxn Direct Dual-Hobbed Drive w/ 100N Extrusion Force

Nozzle: 0.4mm/0.016in, Brass or Hardened Steel

Hotbed

Magnetic Hotbed MK53

Maximum Temperature: 120C/248F

Print Surface

Wuxn BuildTak or Wuxn Coated PEI

Cooling

Noctua 3 Fan Part Cooling Subsystem

Airflow: [5 + 3.62 + 3.62]CFM

Linear Actuators

Gates Belt Driven LDO Profile Linear Guide Rails

Filament

Compatibility

PLA, PLA+, Silk PLA, PLA-CF, PET, PETG, CF-PETG, ASA, CF-ASA, ABS, CF-ABS, PVS, Nylon, CF-Nylon, TPU, TPE, HIPS, Polycarbonates (PC), CF-PC, Wood-Polymer Composites, Hemp-Polymer Composites, & Metal-Polymer Composites (Brass, Copper, Stainless Steel 316L, Stainless Steel, Stainless Steel 17-4).

Wuxn Classic Filament: PLA, PETG, ASA, ABS, & TPU.

Layer Resolution

[0.05-0.3]mm/[0.001-0.01]in

Printing Speed

A Maximum of [200mm/s at 10,000mm/s^2]/[8in/s at 394in/s^2]

Weight

9.75kg/21.5lbs

Assembly

Every Wuxn WXR Ecosystem is assembled, calibrated, & tested in Colorado, USA. All units include; Wuxn Classic PLA, WuxnSlicer, Wuxn WXR Users Manual, and Accessories.


WuxnCare or WuxnCare+ may be purchased at an additional cost.






Electrical

Mainboard

Wuxn 32 bit Microcontroller w/ Integrated Fuses

Processor: ARM Cortex-M3 CPU

Screen

Wuxn Full Color Thin Film Transistor Touchscreen

Dimensions: 110mm/4.3in

Stepper Motors

Wuxn Nema Stepper Motors controlled by Trinamic Microstepping

Sensors

Wuxn Induction Bed Leveling and Gantry Alignment with Drift Compensation, Wuxn Infrared Automatic Filament Loading and Runout Detection, Wuxn Integrated Circuit Sensorless Homing, & Wuxn Resistance-Temperature Transfer Function Thermistors.

Power Supply

Wuxn MeanWell Power Supply w/ Integrated Silent Fan

Input Power Requirements: 110/220VAC [Manual Switching]



Firmware & Software

Firmware

Wuxn Mainboard Firmware is a variant of Marlin. Marlin was built by and for RepRap enthusiasts to be a straightforward, reliable, and adaptable printer driver that “just works”. Wuxn has added unique features such as, Wuxn Out-of-Box Wizard, Diagnostics Wizard, Set Wizard, First Layer Wizard, PID Wizard, WuxnSlicer integration, and more to minimize the required end-user knowledge and time.

Software

WuxnSlicer 1.2.7 is a derivative of Ultimaker Cura. Ultimaker Cura is the world’s most popular 3D printing software. Wuxn has added unique features such as, preconfigured Wuxn machine, material, and print profiles, preconfigured material and print profile selection process, custom Wuxn user interface, basic or advanced print setting modes, automatic g-code generation, and more to minimize the required end-user knowledge and time.

Connectivity

Full Size SD Card, USB Stick, & USB Cord

Language Interface

English/Chinese/Italian/Korean/Czech/German/French

Supports (OS)

Windows 10/11, Mac OS X, & Linux
